HP NonStop Pathway/iTS Web Client Programming Manual—520270-003
7-1
7 Introduction to Pathway/iTS 1.1
Pathway/iTS 1.1 provides large message (more than 32,000 bytes) communication
support between SCOBOL requesters (and converted Java clients) and Pathway
servers. Today, support for large message communication is available to TS/MP
Pathsend requesters in the form of context-sensitive APIs
(SERVERCLASS_DIALOG_* APIs). Pathway/iTS 1.1 intends to support large
message communication by introducing a new TCP process called PATHTCP4. The
new TCP component of Pathway/iTS 1.1 is a Pathsend requester and uses Pathsend
APIs to forward the application message to Pathway servers. Four new SCOBOL
verbs (DIALOG-ABORT, DIALOG-BEGIN, DIALOG-END, and DIALOG-SEND) are
introduced in Pathway/iTS 1.1 to support large message communication.
To process the SEND verb in SCOBOL program (and in converted Java clients),
PATHTCP4 makes SERVERCLASS_SEND_ API call, and to process the DIALOG-*
verbs, PATHTCP4 makes SERVERCLASS_DIALOG_* API calls. PATHTCP4 never
communicates to any PATHMON process directly for link management activities. The
SCUP and Web Client components of Pathway/iTS 1.1 are also changed to support
the new functionalities. Any existing Pathway/iTS 1.0 application can be used along
with PATHTCP4 component of Pathway/iTS 1.1 with minimal changes or no changes
to the applications. However, for compatibility reasons, Pathway/iTS 1.1 package also
includes PATHTCP3, the legacy TCP component.
