TR3271 Management Programming Manual

COMMANDS AND RESPONSES
RESETSTATS Command
If this token is not present, and the LINE or SU object is
specified, the command affects the named object only.
(ZSPI-TKN-) MANAGER, SSID, MAXRESP, CONTEXT, RESPONSE-TYPE,
ALLOW-TYPE, and COMMENT are standard SPI tokens. With the
exception of the ZSPI-TKN-SSID token, which your management
application must pass to SSINIT, these tokens are optional.
These tokens are described in "SPI Standard Definitions" in
Section 5 and the Distributed Systems Management (DSM)
Programming Manual .
Tokens in Response Buffer
ZSPI-TKN-SSID is an echo of the subsystem ID value provided
by your application. This token is described in "SPI Standard
Definitions" in Section 5 "Common Definitions," and the
Distributed Systems Management (DSM) Programming Manual .
ZSPI-TKN-SERVER-VERSION indicates the software release version of
the TR3271 subsystem. See "SPI Standard Definitions" in Section
5 for details.
ZTR3-MAP-RSTATS-LINE is the extensible structured token that
lists the statistical counters obtained during the sample period
for the line. It has the token number ZTR3-TNM-RSTATS-LINE and
the DDL definition ZTR3-DDL-RSTATS-LINE.
Each counter is defined in a separate field. The fields in the
ZTR3-MAP-RSTATS-LINE token are as follows:
ZRESET-TIME is the time that the TR3271 subsystem read the
counters. This time indicates the end of the sample period.
ZSAMPLE-TIME is the last time that the counters were reset.
This time indicates the beginning of the sample period.
ZTR3-LINE-CLB is a structure that contains statistical infor-
mation about the CIU-to-LIU Bus (CLB) level for the specified
line. ZTR3-LINE-CLB consists of the following fields:
ZTOTAL-FRAME is the number of CLB frames that were sent
from and received by the TR3271 subsystem for the specified
line.
ZBCC-ERR is the number of BCC errors that occurred at the
CLB level for the specified line.
ZFRAME-ERR is the number of frame errors that occurred at
the CLB level for the specified line.
6-79
