TR3271 Management Programming Manual

TR3271 EVENT MANAGEMENT
157: ZTR3-EVT-CSS-FRAME-ERR
ZTR3-TKN-ADDR-CTL is the A and C fields. It corresponds to the
value param1 in the message text.
ZTR3-TKN-TYPE-SEQ is the T and S fields. It corresponds to the
value param2 in the message text.
For details on any of the EMS tokens, refer to the Event
Management Service (EMS) Manual .
Volatile Tokens
ZEMS-TKN-CU is a standard EMS token that contains the controller
and unit number. This token is present in the event buffer only
if the controller uses subchannel-type I/O addressing.
Event-Message Text
In the message text, ldev corresponds to the value of ZEMS-
TKN-LDEV, n,n,%nn,%nnn corresponds to the value of ZEMS-MAP-
EXIOADDR, ldevname corresponds to the value of ZEMS-TKN-LDEVNAME,
path corresponds to the value of ZCOM-TKN-NEW-PATH, frame-
err corresponds to the value of ZTR3-TKN-FRAME-ERR, param1
corresponds to the value of ZTR3-TKN-ADDR-CTL, and param2 corre-
sponds to the value ZTR3-TKN-TYPE-SEQ.
Probable Cause
An invalid frame was received. It is normal for this event
to occur when the CLIP resets itself. Generally, the system
recovers automatically.
7-46
