D Installing SWID, DSM/SCM PVU, and Planner Interface
(PI) Client Software
NOTE:
• You must have installed both the DSM/SCM SPR and the corresponding client version before you receive an RVU
SUT. All newly shipped NonStop systems will have the latest DSM/SCM SPR installed. The latest DSM/SCM client
version is available only on the SUT unless you have ordered new system consoles.
• Always install the latest SWID PVU at the same time you install a new DSM/SCM PVU to avoid a fingerprint or
mismatched file problem. (DSM/SCM uses SWID to determine if a file has changed by a method called fingerprinting.
If an existing file has a different fingerprint from a newer file, the newer version replaces the existing file.) Your
newly shipped system will have the latest SWID SPR.
• DSM/SCM is not installed and not supported on 64-bit consoles. If you have a Windows 2008 (64-bit) console,
use the instructions for installing SWID and DSM/SCM using NonStop Software Essentials in “Using DSM/SCM
and NonStop Software Essentials to Install SPRs” (page 133).
Alerts
• “Determine the Product Version of DSM/SCM on the Host System” and “Determine the Product
Version of DSM/SCM on the Client”.
• Save the current configuration database. (See “Save the Current Configuration File
(CONFxxyy)” (page 41)).
• Keep the startup TACL windows, the EMS Event Stream window, and the DSM/SCM client
interface windows open whenever you are performing a Build/Apply. Otherwise, Build/Apply
errors will result.
• If you receive an error indication in the Request Status window, you might have to re-initiate
the Build/Apply. See the DSM/SCM Messages Manual to learn the nature and severity of
the problem.
Determine the Product Version of DSM/SCM on the Host System
To determine which product version of DSM/SCM is currently installed on your system, use the
VPROC command to determine the product version of TAEXE (Apply product of DSM/SCM) and
CBEXE (Build product of DSM/SCM).
At a TACL prompt, enter:
> volume $dsmscm_vol.ZDSMSCM
> vproc taexe
> vproc cbexe
If your VPROC commands do not display the version for this RVU, install the correct DSM/SCM
product version by following the procedures in “Copy (RESTORE) the H02 DSM/SCM Product
Version to Disk (If Necessary)” (page 148).
The DSM/SCM version for this RVU is ACQ.
Determine the Latest SWID Product
Using the VPROC command, identify the SWID SPR. The SWID version for this RVU is AAS.
Determine the Product Version of DSM/SCM on the Client
To determine which product version of DSM/SCM client software is installed, start the DSM/SCM
Planner Interface. Before prompting you to log on, the About DSM/SCM window briefly displays
version information. For example:
154 Installing SWID, DSM/SCM PVU, and Planner Interface (PI) Client Software
