4 Upgrade Checklist
Use the upgrade checklist in “Upgrade Checklist” (page 37) to track your progress as you perform
the tasks required to upgrade to this RVU and the checklists in Table 10 and Table 11 (page 37)
to record the information needed when performing these tasks.
CAUTION: The upgrade steps must be performed in the order specified in this chapter.
NOTE: To perform these upgrade tasks, you need the NonStop System Console (NSC) Installer
Guide. If your system has CLIMs, you also need the Cluster I/O Protocols (CIP) Configuration and
Management Manual the CLuster I/O Module (CLIM) Software Compatibility Reference, NonStop
Firmware Matrices.
NOTE: If you are migrating from a J06.06 or later RVU, you can perform an online upgrade of
the CLIMs before upgrading the host system. (See the Cluster I/O Protocols (CIP) Configuration
and Management Manual for online CLIM software upgrade procedures.) If you have not already
upgraded your CLIMs, you will need to upgrade the CLIMs offline as shown in this procedure.
You might have to update the service processor (SP) firmware on NonStop S-series systems for
IOMF2 PMF CRUs.
Required Information Checklists
Gather the information in Table 10 before you start. Obtain firmware levels from the CLuster I/O
Module (CLIM) Software Compatibility Reference.
Table 10 Required Information Checklist, Before You Start
ValueType of Information
Volume where SYSnn subvolumes are located (usually $SYSTEM)
Current SYSnn (before upgrading to this RVU)
FCSA firmware
G4SA firmware
c7000 enclosure ServerNet Switch firmware
OA firmware level
• ServerNet Switch firmware
• ServerNet Switch FPGA firmware
CLIM software
CLIM firmware
S-Series Interoperability firmware
• Service Processor
• Service Processor B
IOAM or VIO firmware
• ME firmware
• ME FPGA firmware
SWAN firmware
36 Upgrade Checklist
