Replacing External Tape Drive CRUs Online

Replacing External Tape Drive CRUs Online
This procedure describes how to prepare, replace, and resume operations on tape
drives connected to a differential SCSI port on a PMF CRU or IOMF CRU.
For information about tape drives connected to a 6760 ServerNet/DA SCSI
plug-in card (S-PIC), see the 6760 ServerNet/DA manual.
●
Some tape drives are customer replaceable units (CRUs). Some are field
replaceable units (FRUs). See Definitions and Service Classes of CRUs and
FRUs.
●
For instructions for removing and installing a tape drive, see the specific tape
drive or tape library manual. See List of Tape Drive Manuals.
●
 Note: On PMF2 CRUs (S7600, S74000, and later) and IOMF 2 CRUs, the
differential SCSI port has an internal SCSI pass-through terminator. On earlier PMF
CRUs (S7000, S7400, S70000, and S72000) and IOMF CRUs, an external SCSI
passthrough terminator is connected between the cable and the differential SCSI port.
See Location of Differential SCSI Port on PMF/IOMF CRU.
Preparation
1 Inspect the replacement tape drive.
Unpack the drive. Look for damage, including bent or broken connector pins.
If the drive is damaged, do not install it. Order a replacement and return the
drive.
2 On 517x and 519x tape drives, check that the boards and firmware are the
minimum acceptable revisions or higher.
See Minimum Hardware/Firmware Revisions for 517x and 519x
Replacement Tape Drives.
3 If the replacement tape drive has a different model number than the existing
drive, verify that the new drive is supported on the system and the port. See
the manual for the replacement tape drive in List of Tape Drive Manuals for
the hardware and software requirements.
Replacement
3 Stop the tape drive using OSM, TSM, or SCF.
4 Remove and replace the tape drive using the instructions in the tape drive or
tape library manual. See List of Tape Drive Manuals.

Summary of content (14 pages)

PAGE 1
Replacing External Tape Drive CRUs Online This procedure describes how to prepare, replace, and resume operations on tape drives connected to a differential SCSI port on a PMF CRU or IOMF CRU. ● For information about tape drives connected to a 6760 ServerNet/DA SCSI plug-in card (S-PIC), see the 6760 ServerNet/DA manual. ● Some tape drives are customer replaceable units (CRUs). Some are field replaceable units (FRUs). See Definitions and Service Classes of CRUs and FRUs.
PAGE 2
Resuming Operations The following procedure resumes operations on a replacement tape drive. The procedure uses an example drive named $TAPE1. 5 If the SCSI port on the PMF CRU, IOMF CRU, or ServerNet/DA is not configured for a tape drive or if the replacement drive has a different model number than the previous drive, delete the previous drive and add the new drive using SCF.
PAGE 3
Definitions and Service Classes of CRUs and FRUs NonStop S-series components are divided into two categories: customer-replaceable units (CRUs) and field-replaceable units (FRUs). FRUs can be replaced only by an HP authorized service provider. See Replaceable Units Definitions in the Service Information section of the Support and Service library in NTL. For the classification of specific units and part numbers, see Part Numbers in the Service Information section of the Support and Service library in NTL.
PAGE 4
Ethernet 4 ServerNet adapter (E4SA) Fast Ethernet ServerNet adapter (FESA) ServerNet cables ServerNet wide area network (SWAN) concentrator System console 525x, except 5259 Token-Ring ServerNet adapter (TRSA) Class-3 CRUs: 6760 ServerNet/DA Common Communications ServerNet adapter (CCSA) Fiber-optic plug-in card (F-PIC) Fiber-optic ultra SCSI extender Group service LED cable assembly, front IOMF CRU Memory units (MDCs and DIMMs) Modular ServerNet expansion board (MSEB) MSEB PIC PMF CRU SCSI plug-in card (
PAGE 5
List of Tape Drive Manuals See these publications for removal and installation instructions. Tape Drive Publication 5142 external digital audio tape (DAT) drive 5142-xSE Rackmount Tape Subsystem Users Guide. Documentation is also shipped with the tape drive. 5150 digital linear tape (DLT) drive Documentation is shipped with the tape drive. 5155 digital linear tape (DLT) drive in 9710 tape library 9710 (Storage Tek) Addendum for NonStop servers.
PAGE 6
5257 digital linear tape (Super DLT) drive 5257/5257ACL Installation and Users Guide. 5258ACL digital linear tape (Super DLT) drive 5258/5258ACL Installation and Users Guide. 5259 digital linear tape (Super DLT) drive in L700 tape library L700 (CTL700) Installation and Operations Guide (located in the Hardware Service and Maintenance Publications category of the Support and Service library). Contact your service provider. 9490 cartridge tape drive 9490 documentation is shipped with the tape drive.
PAGE 7
PAGE 8
Figure: Location of Differential SCSI Port on PMF/IOMF CRU
PAGE 9
Minimum Hardware/Firmware Revisions for 517x and 519x Replacement Tape Drives Verify that the specified component of the replacement tape drive is at least at these revision levels: Tape Drive 517x 5190 5190ACL 5194 5194ACL Component Display board Control board Buffer board SCSI interface board N. A. N. A. N. A. N. A. Minimum Hardware/Firmware Revision Level 6.40 6.77 or 6.78 6.80 6.
PAGE 10
Stopping the Tape Drive You can use the OSM Service Connection, the TSM Service Application, or SCF to stop a tape drive. Using OSM: a. Log on to the OSM Service Connection. b. In the tree pane, click the Tape Collections icon, right click the Tape Drive icon, and select Actions. c. In the Actions dialog box: - Under Select Component, select Tape Drive. - Under Available Actions, select Stop. The Confirm Stop dialog box appears. Click OK.
PAGE 11
Deleting and Adding a Tape Drive Using SCF: To delete the drive, enter: -> STOP TAPE $Tape1 -> STATUS $Tape1 -> DELETE $Tape1 -> INFO $Tape1 ;stops the tape drive ;verifies drive is in the stopped state ;removes drive from configuration list ;verifies drive has been removed To add the drive back, enter: -> ADD TAPE $Tape1, SENDTO STORAGE, LOCATION (1,1,55) -> INFO $Tape1
PAGE 12
Verifying the SCSI Port is Configured to Support a Tape Drive Using OSM or TSM: a. Log on to the OSM Service Connection or TSM Service Application. b. In the tree pane, select the tape icon. c. Click the attributes tab of the detail pane and check the following: ● OSM: Under Controller Path, check the Configured Controller Location Example: PMF.SAC-3.GRP-1.MOD-1.Slot-50 ● TSM: Check the Adapter Location: Example: Group 1, Module 1, slot 50 Sac 3 For SCF: Enter the SCF INFO TAPE, DETAIL command.
PAGE 13
Starting a Tape Drive You can use the OSM Service Connection, the TSM Service Application, or SCF to start a tape drive. Using OSM: a. Log on to the OSM Service Connection. b. In the tree pane, click the Tape Collections icon, right click the Tape Drive icon, and select Actions. c. In the Actions dialog box: - Under Select Component, select Tape Drive. - Under Available Actions, select Start. The Confirm Start dialog box appears. Click OK.
PAGE 14
Resetting a Tape Drive Using SCF: Check the current status of the tape drive: -> STATUS $Tape1 If the drive is not in the STOPPED state, substate DOWN, enter: -> RESET $Tape1 Check the status again and verify the drive is in the STOPPED state, substate DOWN : -> STATUS $Tape1 Start the tape drive: -> START $Tape1 Verify the status is STARTED: -> STATUS $Tape1
