HP Server Extraction Handle Installation

Table Of Contents

Hewlett-Packard Development Company, L.P.

April 2004 v1

Printed in the U.S.A.

The following includes steps to install the extraction handle in the hp Integrity rx1600 Server. The extraction handle is

used when extending the server from a rack.

Related Documents

Complete server installation and removal instructions can be found in both of the following sources:

· The Operations and Maintenance Guide, on the HP Server Documentation CD-ROM shipped with your HP Server.

· The Operations and Maintenance Guide for your HP Server can be viewed and printed from the HP web site:

ttp://docs.hp.com

Tool Required

· T10 Torx driver

Installing the Extraction Handle

The installation procedure requires removal of the right front bezel.

1. Remove the T10 screw securing the right front bezel to the chassis.

2. Pull the right front bezel to the right, away from the chassis.

3. Insert the ends of the extraction handle into perforated chassis holes shown in Figure 1.

4. Rotate the handle to the horizontal position.

5. Push the handle in until it snaps into place as shown in Figure 2.

6. Replace the right front bezel and secure it with the T10 screw.
