Table 5-2 Return codes (continued)
ActionCauseMeaningValue
Create a conrep.xml file with the EFI
variables that should be read from
NVRAM.
There is no conrep.xml file in the
current directory.
The conrep.xml file was
not found
8
No action is required. This is not an
error, only a warning.
The conrep.xmlfile has some
variables that do not exist in the
current system. Conrep cannot
capture these variables.
At least one EFI variable in
the conrep.xml file was not
found in the system.
9
If root does not have permission to read
the raw_var file of an EFI variable, this
variable must be removed from
conrep.xml.
The user does not have permission
to read the raw_var file in the
/sys/firmware/efi/vars/VAR_NAME-GUIDdirectory.
Error reading an EFI variable10
Change the permissions of the
conrep.dat file.
The user does not have permission
to write to the conrep.dat file.
Error writing to the
conrep.dat file
11
cpqacuxe
Synopsis
• Capture: CPQACUXE -C FILENAME [-internal | -external] -E FILENAME
• Input: CPQACUXE -I FILENAME [-internal | -external] [reset] -E FILENAME
• Input with reset: CPQACUXE -reset FILENAME [-internal | -external] [reset]
-E FILENAME
Description
The cpqacuxe utility operates on the configuration of storage array controllers. The cpqacuxe
utility enables the array configuration on one server to be replicated on other servers with similar
array storage resources. The cpqacuxe utility is located in the utilities directory in the toolkit
as a tar file. The main toolkit launch script expands the tar file before executing it.
The cpqacuxe utility has three modes of operation:
• In capture mode, it reads the configuration of all internal and external array controllers that
are connected to a server and saves this data to a file. You can then use this file to replicate
the array configuration on other servers that have similar storage resources.
• In input mode, it applies the array configuration that is specified in a file to a target server.
You can create this file using the capture mode and leave it unmodified, edit the capture
file, or even create the file from scratch.
• In input mode with reset, it applies the array configuration that is specified in a file to a target
server, clearing any existing controller configuration with total data loss. You can use this
mode to overwrite the current controller array and logical drive settings.
cpqacuxe capture file
The cpqacuxe utility captures the configuration of all array controllers on the server to a capture
file. This capture file can then be used in input mode to replicate the configuration to other array
controllers. Also, the capture file can be edited and then reused in input mode. You can then use
this file to replicate the array configuration on other servers that have similar storage resources.
Use of the -internal or -external command line switches effectively filter the controllers captured.
For example, if the -external switch is used, any controllers internal to the host computer are not
captured in the output file.
A typical array configuration capture file is similar to the following:
