A Parts Information
This appendix provides server part information, such as:
• Description
• Manufacturing part number
• Replacement part number
• Exchange part number
Field Replaceable Parts List
The items in this list and the corresponding item numbers are the field replaceable units (FRUs)
for the HP Integrity rx4640 server.
NOTE: The item numbers listed below are used with the part illustrations in order to identify
the nomenclature of the part. Part numbers are found by using the part nomenclature from this
list to select the correct part from the HP Partsurfer. If a I/O baseboard needs to be replaced,
remove processors, DIMMs, and adapter boards and transfer these to the new board. Ensure all
jumper and switch settings on the old board are transferred to the new board.
Some part numbers shown in Table A-1 have two entries. The second entry is for the Restriction
of the Use of Certain Hazardous Substances (RoHS) compliant parts.
Table A-1 Parts List
Part Number
Exchange
Part Number
Replacement
Mfg. Part
Number
Description
PCA Boards
A6961-69007A6961-67007A6961-60007PCA, Processor Extender
A6961-69207A6961-67207A6961-60207PCA, Processor Extender - (RoHS)
A6961-69401A6961-67401A6961-60201PCA, I/O baseboard (includes VRMs)
A6961-69411A6961-67411A6961-60401PCA, I/O baseboard (includes VRMs) - (RoHS)
A6961-69511A6961-67411A6961-60401PCA, I/O baseboard (includes VRMs) - (RoHS - dual core
processors only)
A6961-69204A6961-67204A6961-60204PCA, 16 slot Memory Board
A6961-69804A6961-67804A6961-60804PCA, 16 slot Memory Board - (RoHS)
A9739-69007A9739-67007A7124-04006PCA, 32 slot Memory Board
A9739-69008A9739-67008A7124-04008PCA, 32 slot Memory Board - (RoHS)
NoneA6961-67005A6961-60005PCA, Midplane Riser Board (Apian)
A6961-69105A6961-67105A6961-60105PCA, Midplane Riser Board (Apian) - (RoHS)
NoneA6961-67024A6961-04075PCA, SCSI Backplane/Management Assy, includes Simplex
board
NoneA6961-67025A6961-04076PCA, SCSI Backplane/Management Assy, includes Simplex
board - (RoHS)
NoneA6961-67106A6961-60106PCA, SCSI Duplex Board (HP-UX)
NoneA6961-67206A6961-60206PCA, SCSI Duplex Board (HP-UX) - (RoHS)
NoneA6961-67008A6961-60008PCA, Front Panel Display
NoneA6961-67108A6961-60108PCA, Front Panel Display - (RoHS)
