Table A-1 Parts List (continued)
Part Number
Exchange
Part Number
Replacement
Mfg. Part
Number
Description
A7217-60001A7217-6000124” CRT Color Monitor (Prod # P7217A)
C1099-67001C1099-62000Serial Console (Prod # C1099A)
C1099-67002C1099-62000Serial Console ROM Replacement Kit (Prod # C1099A)
Depends on product optionsUSB Keyboard and Mouse (Prod # A7861A)
A7782-63001A7782-63001USB to PS/2 Adapter (Prod # A7782A)
