• Serial port for modem console
• Duplication of console screen content across all consoles
Hard Disk Drives
• Two low-profile, hot-pluggable Ultra320 SCSI disk bays
• Disk options:
— 36 GB 15K RPM SCSI disk
— 73 GB 15K RPM SCSI disk
— 146 GB, 10K RPM SCSI disk
— 300 GB, 10K RPM SCSI disk
• Minimum server configuration includes one hard disk drive
Data Pathing Information
Table 1-2 shows information about data pathing in the HP Integrity rx4640 server.
Table 1-2 Data Pathing
PathDevice IDFunction
Number
Device
Number
Bus NumberSlot ID
Acpi(HWP0002,PNP0A03,100)/Pci(1|0)0x002100012001
Acpi(HWP0002,PNP0A03,100)/Pci(2|0)0x164500022002
Acpi(HWP0002,PNP0A03,400)/Pci(1|0)0x231200018003
Acpi(HWP0002,PNP0A03,400)/Pci(2|0)0x01A700028004
Acpi(HWP0002,PNP0A03,500)/Pci(1|0)0x000B0001A005
Acpi(HWP0002,PNP0A03,500)/Pci(2|0)0x10290002A006
Acpi(HWP0002,PNP0A03,200)/Pci(1|0)0x102900014007
Acpi(HWP0002,PNP0A03,600)/Pci(1|0)0x01A70001C008
Supported Operating Systems
The following operating systems are supported on the entry-class HP Integrity servers:
• HP-UX 11i Version 2 (B.11.23)
• HP OpenVMS I64
• Microsoft Windows Server 2003
• Red Hat Enterprise Linux 4
• SuSE Linux Enterprise Server 10
For more operating system information, see Appendix B (page 117).
20 Introduction
