Accessing a Pedestal Mounted Server
The HP Integrity rx4640 server is also designed to be pedestal mounted. You do not need to
remove the pedestal from the server to gain access to internal components. The front bezel, front
cover, and top cover can be removed with the pedestal attached to the server.
WARNING! Ensure that the HP server is properly grounded when performing
remove-and-replace procedures. Use an antistatic wrist strap and grounding mat similar to those
found in the HP Electrically Conductive Field Service Kit.
Figure 4-2 Pedestal Mounted HP Integrity rx4640 Server
Removing and Replacing the Front Bezel
The server does not have to be turned off to remove the front bezel. Figure 4-3 shows how to
remove the front bezel.
