• The web session will timeout after 15 minutes if no mouse or keyboard activity is detected in
the web interface and the vMedia, RSC, or IRC are not launched. An inactivity timeout
configuration option is currently unavailable.
• A slight delay might be observed between the physical and virtual mouse pointer.
NOTE: If you run system discovery utilities such as MAPPER or IOSCAN, the output might display
an extra keyboard and mouse that are not physically connected. This is a consequence of the IRC
feature.
Browsers and Client Operating Systems that Support the IRC
You can view the list of supported browsers and client operating systems for IRC and vKVM on
the HP website at http://www.hp.com/go/integrityilo.
IRC-Supported Resolutions and Browser Configurations
This section provides information on Microsoft Windows and HP-UX graphics settings for the IRC.
Microsoft Windows Server 2003 and HP-UX Graphics Resolution Settings for the IRC
To properly access and view the IRC and optimize performance, set your Windows-based HP
Integrity server to the specifications listed below.
For display and mouse properties, the following settings are suggested:
Server Display Properties
• Set the background to plain (no wallpaper pattern) on the host server.
• Set the client screen resolution higher than the host server for best remote console performance.
• Set the display resolution to 800 x 600 pixels, or the maximum supported resolution of 1024
x 768 pixels.
NOTE: The resolution on the host server must not exceed 1024 x 768 pixels. Higher
resolutions can produce unpredictable results.
• Set the display color mode to 256 colors, or 24-bit colors.
Server Mouse Properties
• For mouse pointer scheme, select None.
• Select Disable Pointer Trails.
• Deselect Enable Pointer Shadow.
• Select Motion or Pointer Options, and set the pointer speed slider to the middle position.
• Deselect Enhanced pointer precision.
To automate setting an optimal mouse configuration, download the Lights-Out Optimization utility
from the HP website at:
http://www.hp.com/servers/lights-out
Click the Best Practices graphic and select Maximize Performance .
Console Settings
The default console is the serial console.
HP recommends leaving the console settings on serial to preserve SSH access and the iLO 2 console
logs.
