Table 59 /map1/textredirectsap1 Properties
Access and ValuesDescriptionProperty Name
Read-only
The value is set to Enabled.
Shows whether the text redirection is enabled.EnabledState
Read-only
The value is set to SMCLP.
A string sequence used for terminating text
redirection session and returning to SM CLP.
SessionTerminateSequence
Enter SMCLP at the MP Main Menu to
return to the SM CLP interface.
Read-only
The value is set to MP Main Menu
Interface.
Description of this text redirection service access
point.
Description
Read-only
The value is set to MP Main Menu
Uniquely identifies this access point.Name
Verbs
cd Changes the current default target.
help Displays context-sensitive help.
show Displays information.
start Switch to MP Main Menu.
Opening the System Console Interface from SM CLP
This section provides information on how to open the system console from the SM CLP.
Target: system1/consoles1/textredirectsap1
This target represents the system text console (currently launched through the iLO 2 CO command).
Table 60 shows textredirectsap1 target properties.
Table 60 /system1/consoles1/textredirectsap1 Properties
Access and ValuesDescriptionProperty Name
Read-only
Set to Enabled.
Shows if the test redirection is
enabled.
EnabledState
Read-only
Set to Esc.
A string sequence used for terminating
text redirection session and returning
to SM CLP.
SessionTerminateSequence
Enter Esc at the system console to return to the
SM CLP interface.
Read-only
Set to System Test Console Interface.
Description of this text redirection
service access point.
Description
Read-only
Set to System Test Console.
Uniquely identifies this access point.Name
Verbs
cd Changes the current default target.
help Displays context-sensitive help.
show Displays information.
start Switch to system text console.
Switching Between the System Console and the SM CLP
The following examples show commands used to switch between the system console and the SM
CLP.
SMASH Server Management Command Line Protocol 151
