Properties
VersionString=F.01.57
This example displays all the firmware revisions.
</>hpiLO-> show /map1/swinventory1/swid*
/map1/swinventory1/swid1
TargetType=MP FW
VersionString=F.01.57
/map1/swcollection1/swid2
TargetType=BMC FW
VersionString=01.60
/map1/swcollection1/swid3
TargetType=EFI FW
VersionString=ROM A 05.11, ROM B 255.255
/map1/swcollection1/swid4
TargetType=System FW
VersionString=ROM A 62.03, ROM B 255.255, Boot ROM B
/map1/swcollection1/swid5
TargetType=PDH FW
VersionString=00.0b
/map1/swcollection1/swid6
TargetType=UCIO FW
VersionString=03.03
/map1/swcollection1/swid7
TargetType=PRS FW
VersionString=00.05 UpSeqRev: 09, DownSeqRev: 07
or
</>hpiLO-> show -level all swid*
Firmware Upgrade
Firmware upgrades enhance the functionality of iLO 2.
The MP firmware is packaged along with system, BMC, and FPGA/PSOC firmware. You can
download and upgrade the firmware package from the HP website at http://www.hp.com/go/
bizsupport.
IMPORTANT: When performing a firmware upgrade that contains system programmable
hardware, you must properly shut down any OS that is running before starting the firmware upgrade
process.
Select Download drivers and software, select your server, and follow the directions provided.
After the upgrade, reconnect and log in as user Admin and password Admin (case sensitive).
TIP: Before performing certain iLO 2 functions, verify that you have the supported firmware
version required to carry out the task.
Remote Access Configuration
Integrity iLO 2 supports the use of Telnet and SSH to access the iLO 2 MP command line interface.
154 Using iLO 2
