Telnet SM CLP Targets
This section describes targets, their properties, and supported verbs necessary to enable or disable
Telnet access to iLO 2.
Target: map1/telnetsvc1
The telnetsvc1 target represents the telnetsvc service provided by map1.
Table 64 shows telnetsvc1 target properties.
Table 64 telnetsvc1 Properties
Access and ValuesDescriptionProperty Name
Read-only
The following are valid values:
Shows whether Telnet is enabled or disabled.EnabledState
Enabled, Disabled
Read-only
Set to telnet
The protocol this service provides.Protocol
Verbs
start Enables iLO 2 Telnet service.
show Displays information.
stop Disables iLO 2 Telnet service.
help Displays context-sensitive help.
Telnet Examples
The following examples show specific Telnet commands.
Enable Telnet Service
</>-> start /map1/telnetsvc1
Disable Telnet Service
</>-> stop /map1/telnetsvc1
SSH
This section describes targets, their properties, and supported verbs necessary to enable or disable
SSH access to iLO 2.
Target: map1/sshsvc1
The sshsvc1 target represents the SSH service provided by map1.
Table 65 shows sshsvc1 target properties.
Table 65 sshsvc1 Properties
Access and ValuesDescriptionProperty Name
Read-only
The following are valid values:
Shows whether SSH service is enabled or
disabled.
EnabledState
Enabled, Disabled
Read-only
Set to SSH.
The protocol this service provides.Protocol
Verbs
start Enables iLO 2 SSH service.
stop Disables iLO 2 SSH service.
SMASH Server Management Command Line Protocol 155
