show Displays information.
help Displays context-sensitive help.
SSH Examples
The following examples show specific SSH commands.
Enable SSH Service
</>-> start /map1/sshsvc1
Disable SSH Service
</>-> stop /map1/sshsvc1
Network Configuration
Network commands enable you to display or modify network settings.
SM CLP Network Targets, Properties, and Verbs
This section describes targets, target properties, and supported verbs necessary to implement the
iLO 2 network configuration through SM CLP.
Target: map1/enetport1
The enetport1 target represents capabilities and management of the iLO 2 MP Ethernet port.
Table 66 shows enetport1 target information.
Table 66 enetport1 Properties
Access and ValuesDescriptionProperty Name
Read/write
Boolean values accepted.
Specified if the iLO 2 AutoSense feature is
enabled. If it is disabled, iLO 2 network
speed is set to 10 mb/s.
AutoSense
Read-only
The iLO 2 MP MAC address is formatted
as twelve hexadecimal digits
Represents iLO 2 MP MAC address.PermanentAddress
(10203040506) with each pair
representing one of the six octets of the
MAC address.
Verbs
cd Changes the current default target.
help Displays context-sensitive help.
show Displays information.
set Sets a property to a specific value.
Target: map1/enetport1/lanendpt1
The lanendpt1 target represents the iLO 2 LAN endpoint settings.
Table 67 shows lanendpt1 target properties.
Table 67 lanedpt1 Properties
Access and ValuesDescriptionProperty Name
Read-only
The following are valid values:
Represents the iLO 2 MP LAN state.EnabledState
