Table 67 lanedpt1 Properties (continued)
Access and ValuesDescriptionProperty Name
Enabled, Disabled
Read-only
The MAC address is formatted as twelve
hexadecimal digits (010203040506), with each
Represents the iLO 2 MP MAC address.MACAddress
pair representing one of the six octets of the MAC
address.
Verbs
cd Changes the current default target.
help Displays context-sensitive help.
show Displays information.
Target: map1/enetport1/lanendpt1/ipendpt1
The ipendpt1 target represents the iLO 2 MP IP endpoint settings.
Table 68 shows ipendpt1 target properties.
Table 68 ipendpt1 Properties
Access and ValuesDescriptionProperty Name
Read/write
The value of the property must be expressed in
dotted decimal notation.
iLO 2 MP IP address.IPv4Address
Read/write
The value of the property must be expressed in
dotted decimal notation.
iLO 2 MP subnet mask.SubnetMask
Read-only
The following are valid values:
Indicates the configuration method that
resulted in the configuration being
assigned to this ipendpt.
AddressOrigin
Static: The iLO 2 MP IP address and subnet
mask were assigned statically.
DHCP: The iLO 2 MP IP address and subnet
mask were acquired using DHCP.
Verbs
cd Changes the current default target.
help Displays context-sensitive help.
show Displays information.
set Sets a property to a specific value.
Target: map1/dhcpendpt1
The dhcpendpt1 target represents the iLO 2 DHCP client.
Table 69 shows dhcpendpt1 target properties.
Table 69 dhcpendpt1 Properties
Access and ValuesDescriptionProperty Name
Read-only
The following are valid values:
Represents the state of iLO 2
DHCP.
EnabledState
Enabled: The iLO 2 DHCP client is enabled.
