Changes made to the schema during the schema setup process include changes to the following:
• Core classes
• Core attributes
NOTE: Roles such as hpqTargets, and so on, are for extended schema LDAP only. They are not
used in schema-free LDAP.
Core Classes
Table 80 lists the core LDAP OID classes.
Table 80 Core Classes
Assigned OIDClass Name
1.3.6.1.4.1.232.1001.1.1.1.1hpqTarget
1.3.6.1.4.1.232.1001.1.1.1.2hpqRole
1.3.6.1.4.1.232.1001.1.1.1.3hpqPolicy
Core Attributes
Table 81 lists the core LDAP OID attributes.
Table 81 Core Attributes
Assigned OIDAttribute Name
1.3.6.1.4.1.232.1001.1.1.2.1hpqPolicyDN
1.3.6.1.4.1.232.1001.1.1.2.2hpqRoleMembership
1.3.6.1.4.1.232.1001.1.1.2.3hpqTargetMembership
1.3.6.1.4.1.232.1001.1.1.2.4hpqRoleIPRestrictionDefault
1.3.6.1.4.1.232.1001.1.1.2.5hpqRoleIPRestrictions
1.3.6.1.4.1.232.1001.1.1.2.6hpqRoleTimeRestriction
Core Class Definitions
Table 82, Table 83, and Table 84 define the HP management core classes.
hpqTarget
Table 82 hpqTarget
1.3.6.1.4.1.232.1001.1.1.1.1OID
This class defines target objects, providing the basis for HP products using directory-enabled
management.
Description
StructuralClass Type
UserSuperClasses
hpqPolicyDN—1.3.6.1.4.1.232.1001.1.1.2.1hpqRoleMembership—1.3.6.1.4.1.232.1001.1.1.2.2Attributes
NoneRemarks
