hpqRole
Table 83 hpqRole
1.3.6.1.4.1.232.1001.1.1.1.2OID
This class defines role objects, providing the basis for HP products using directory-enabled
management.
Description
StructuralClass Type
GroupSuperClasses
hpqRoleIPRestrictions—1.3.6.1.4.1.232.1001.1.1.2.5hpqRoleIPRestrictionDefault—1.3.6.1.4.1.232.1001.1.1.2.4
hpqRoleTimeRestriction—1.3.6.1.4.1.232.1001.1.1.2.6hpqTargetMembership—1.3.6.1.4.1.232.1001.1.1.2.3
Attributes
NoneRemarks
hpqPolicy
Table 84 hpqPolicy
1.3.6.1.4.1.232.1001.1.1.1.3OID
This class defines policy objects, providing the basis for HP products using directory-enabled
management.
Description
StructuralClass Type
TopSuperClasses
hpqPolicyDN—1.3.6.1.4.1.232.1001.1.1.2.1Attributes
NoneRemarks
Core Attribute Definitions
Table 85 through Table 90 define the HP management core class attributes.
hpqPolicyDN
Table 85 hpqPolicyDN
1.3.6.1.4.1.232.1001.1.1.2.1OID
This attribute provides the Distinguished Name of the policy that controls the general configuration
of this target.
Description
Distinguished Name—1.3.6.1.4.1.1466.115.121.1.12Syntax
Single ValuedOptions
NoneRemarks
hpqRoleMembership
Table 86 hpqRoleMembership
1.3.6.1.4.1.232.1001.1.1.2.2OID
This attribute provides a list of hpqTarget objects to which this object belongs.Description
Distinguished Name—1.3.6.1.4.1.1466.115.121.1.12Syntax
Multi ValuedOptions
NoneRemarks
Directory Services Schema (LDAP) 203
