Table 90 hpqRoleTimeRestriction (continued)
1.3.6.1.4.1.232.1001.1.1.2.6OID
Single ValuedOptions
This attribute is only used on role objects. Time restrictions are satisfied when the bit
corresponding to the current local side real time of the device is 1, and unsatisfied when the bit
Remarks
is 0. The least significant bit of the first byte corresponds to Sunday, from 12 midnight, to Sunday
12:30 AM. Each more significant bit and sequential byte corresponds to the next consecutive
half-hour blocks within the week. The most significant (8th) bit of the 42nd byte corresponds to
Saturday at 11:30 PM, to Sunday at 12 midnight.
iLO 2-Specific LDAP OID Classes and Attributes
The schema attributes and classes in Table 91 and Table 92 might depend on attributes or classes
defined in the HP management core classes and attributes.
iLO 2 Classes
Table 91 iLO 2 Classes
Assigned OIDClass Name
1.3.6.1.4.1.232.1001.1.8.1.1hpqLOMv100
iLO 2 Attributes
Table 92 iLO 2 Attributes
Assigned OIDClass Name
1.3.6.1.4.1.232.1001.1.8.2.1hpqLOMRightLogin
1.3.6.1.4.1.232.1001.1.8.2.2hpqLOMRightRemoteConsole
1.3.6.1.4.1.232.1001.1.8.2.3hpqLOMRightVirtualMedia
1.3.6.1.4.1.232.1001.1.8.2.4hpqLOMRightServerReset
1.3.6.1.4.1.232.1001.1.8.2.5hpqLOMRightLocalUserAdmin
1.3.6.1.4.1.232.1001.1.8.2.6hpqLOMRightConfigureSettings
iLO 2 Class Definitions
hpqLOMv100
Table 93 hpqLOMv100
1.3.6.1.4.1.232.1001.1.8.1.1OID
This class defines the rights and settings used with HP iLO 2 products.Description
AuxiliaryClass Type
NoneSuperClasses
hpqLOMRightConfigureSettings-1.3.6.1.4.1.232.1001.1.8.2.1
hpqLOMRightLocalUserAdmin-1.3.6.1.4.1.232.1001.1. 8.2.2
Attributes
hpqLOMRightLogin-1.3.6.1.4.1.232.1001.1.8.2.3
hpqLOMRightRemoteConsole-1.3.6.1.4.1.232.1001.1.8.2.4
hpq LOMRightServerReset-1.3.6.1.4.1.232.1001.1.8.2.5
hpqLOMRightVirtualMedia-1.3.6.1.4.1.232.1001.1.8.2.6
NoneRemarks
Directory Services Schema (LDAP) 205
