iLO 2 Attribute Definitions
Table 94 through Table 99 define the iLO 2 core class attributes.
hpqLOMRightLogin
Table 94 hpqLOMRightLogin
1.3.6.1.4.1.232.1001.1.8.2.1OID
Login right for HP iLO 2 products.Description
Boolean-1.3.6.1.4.1.1466.115.121.1.7Syntax
Single ValuedOptions
The attribute is meaningful only on role objects. If TRUE, members of the role are granted the
right.
Remarks
hpqLOMRightRemoteConsole
Table 95 hpqLOMRightRemoteConsole
1.3.6.1.4.1.232.1001.1.8.2.2OID
Remote console right for iLO 2 products. Meaningful only on role objects.Description
Boolean-1.3.6.1.4.1.1466.115.121.1.7Syntax
Single valuedOptions
This attribute is only used on role objects. If this attribute is TRUE, members of the role are granted
the right.
Remarks
hpqLOMRightRemoteConsole
Table 96 hpqLOMRightRemoteConsole
1.3.6.1.4.1.232.1001.1.8.2.3OID
Virtual media right for HP iLO 2 products.Description
Boolean-1.3.6.1.4.1.1466.115.121.1.7Syntax
Single valuedOptions
This attribute is only used on role objects. If this attribute is TRUE, members of the role are granted
the right.
Remarks
hpqLOMRightServerReset
Table 97 hpqLOMRightServerReset
1.3.6.1.4.1.232.1001.1.8.2.4OID
Remote server reset and power button right for HP iLO 2 products.Description
Boolean-1.3.6.1.4.1.1466.115.121.1.7Syntax
Single valuedOptions
This attribute is only used on role objects. If this attribute is TRUE, members of the role are granted
the right.
Remarks
206 Installing and Configuring Directory Services
