1
Cables are not provided with the server.
Integrity iLO 2 Supported Browsers and Client Operating Systems
Integrity iLO 2's web GUI standard features are supported with Microsoft Internet Explorer 6.0
SP1 or Internet Explorer 7, Mozilla Firefox 2.0.0.10.02 or Firefox 3, and HP Secure Web Browser
1.7-13. iLO 2's advanced feature of Integrated Remote Console, a graphical remote console, is
supported only with Internet Explorer browsers and requires DirectX control. All browsers support
the iLO 2 Remote Serial Console and vMedia applets using the 32-bit Java Plug-in 1.6.0_01.
You can view the most current list of supported browsers and operating systems in the Quickspecs
on the HP website at http://www.hp.com/go/integrityilo.
Related Links
• Java™ for HP-UX
◦ http://www.hp.com/products1/unix/java/versions/index.html
◦ http://www.hp.com/products1/unix/java/archives/index.html
• Java for OpenVMS
◦ http://h18012.www1.hp.com/java/alpha
• Firefox for HP-UX
◦ http://www.hp.com/products1/unix/java/firefox/index.html
Note: 1.5.0.00 needs patch
◦ http://www.hp.com/go/firefox
• Firefox for Linux®
◦ http://linuxcoe.corp.hp.com
• Firefox for Windows and Linux
◦ http://www.mozilla.com/firefox
• Browser Support 1.5.0
◦ http://java.sun.com/j2se/1.5.0/system-configurations.html
Security
You must have strong security surrounding the iLO 2 device. HP security requirements for iLO 2
include the following:
Authentication Integrity iLO 2 incorporates authentication techniques with the use of 128-bit
Secure Socket Layer (SSL) encryption. It is password based for web and
password- and key-based for secure shell (SSH).
Authorization Using local accounts, iLO 2 enables you to define up to 19 separate users
and to vary the server access rights of each user. The directory services
capabilities of iLO 2 enables you to maintain network user accounts and
security policies in a central, scalable database that supports thousands of
users, devices, and management roles.
Integrity Integrity iLO 2 incorporates a trusted Java applet for vMedia.
Privacy Integrity iLO 2 uses SSL for web connections, RSL-RC4 encryption for IRC
and remote serial console, and 3DES-CBC/AES128-CBD recommended
encryption algorithms for SSH-based connections. You can enable or disable
Telnet, IPMI over LAN, web, and SSH connectivity.
