Table 11 ARP Ping Commands
DescriptionARP Command
Assigns the IP address to the iLO 2 MP MAC address. This ARP table entry maps the MAC address
of the iLO 2 MP LAN interface to the static IP address designated for that interface.
arp -s
Tests network connections and verifies that the MP LAN port is configured with the appropriate IP
address.
ping
NOTE: The following procedure explains how to use the ARP Ping utility using a PC that is
connected to the network that is on the same physical subnet as the server.
To configure a static IP address using the ARP Ping utility:
1. Obtain the iLO 2 MP MAC address. To set the IP address using ARP, you must know the MAC
address of the iLO 2 MP LAN. You can find the MAC address of the iLO 2 MP LAN on a label
on the server.
IMPORTANT: Make sure you obtain the MAC address to the iLO 2 MP LAN and not the
MAC address to the server core LAN.
2. Verify that an active LAN cable on the local subnet is connected to the MP LAN port on the
server.
3. Access a PC on the same physical subnet as the server.
4. Open a DOS window on the PC.
5. At the DOS command prompt (C: >) , enter arp -s to assign the IP address to the iLO
MAC address.
The syntax is as follows:
arp -s <IP address you want to assign to the iLO MAC address> <iLO
2 MAC address>
Example from Windows
arp -s 255.255.255.0 00-00-0c-07-ac-00
6. At the DOS command prompt, enter ping followed by the IP address to verify that the MP
LAN port is configured with the appropriate IP address. The destination address is the IP
address that is mapped to the iLO MAC address. Perform this task from the PC that has the
ARP table entry.
The syntax is as follows:
ping <IP address just assigned to the iLO MAC address>
Example from Windows
ping 192.0.2.1
7. Use this IP address to connect to the iLO 2 MP LAN.
8. Use web or Telnet access to connect to iLO 2 from a host on the local subnet and configure
the rest of the LAN parameters (gateway, subnet).
Configuring the iLO 2 MP LAN Using the Console Serial Port
The terminal emulation device runs software that interfaces with the server. The software emulates
console output as it would appear on an ASCII terminal screen and displays it on a console device
screen.
To configure the iLO 2 MP LAN using the console serial port (RS-232):
IMPORTANT: Do not configure duplicate IP addresses on different servers within the same network.
The duplicate server IP addresses conflict and the servers cannot connect to the network.
Rackmount Server Connection 37
