Table 14 Supported System Configurations
DescriptionSystem Component
nPartition operating system
• Microsoft Windows Server 2003
• HP-UX 11i v2 or later
• OpenVMS Version 8.3 or later
• Windows 2008
Supported platforms
• rx7640
• rx8640
• Superdome sx2000
You can install the Lights-Out Advanced KVM card on any sx2000-based Integrity server with
updated management processor firmware that provides iLO 2 functionality and uses the web
interface to access iLO 2. The Lights-Out Advanced KVM card must be installed in a PCI-X mode-1
slot. It cannot be used in PCI-X mode 2 slots or in PCIe slots. To determine which slots are mode-1
compatible, see the documentation for your server product. A Lights-Out Advanced KVM card is
required for each hard partition (nPartition) where you want virtual keyboard, video, mouse (vKVM)
and vMedia functionality; Lights-Out Advanced functionality is not currently supported on virtual
partitions (vPar).
TIP: Remember, you do not need an iLO 2 Advanced Pack license key to use this card.
Table 15 lists which features of the Lights-Out Advanced KVM card are available on each operating
system.
Table 15 Availability of Features
USB PortsVGA Graphics PortvMedia
IRC
1
nPartition Operating System
YesYesYesYesWindows
YesNoYesNoHP-UX
YesNoYesNoOpenVMS
Not currently supported under Linux.Linux
Lights-Out Advanced KVM Card for sx2000 Servers 51
