Mid Range PCI Backplane Power Behavior
On Integrity cell-based servers, you can power off the Lights-Out Advanced KVM card separately
from the iLO 2 management processor. For example, you can power off a partition containing a
Lights-Out Advanced KVM card, while keeping other partitions powered on. Or, you can power
off the entire complex (all the partitions). In either case, the iLO 2 management processor is still
accessible because it is powered separately from the partitions.
If iLO 2 is accessed while a partition is powered off, the Lights-Out Advanced KVM card in that
partition could still appear in the partition drop-down lists for vMedia or IRC. However, you will
not be able to start a vMedia or IRC session and the status will be “In use or unavailable”. If a
vMedia or IRC session was already open when the partition was powered off, the session window
remains open, but is not active.
Troubleshooting the Lights-Out Advanced KVM Card
When troubleshooting the Lights-Out Advanced KVM card, consider the following:
• Verify that the card is installed in the proper/supported slot. Be aware of slot restrictions.
• Check for Lights-Out Advanced KVM card seating and connections to the slot connector.
• Check that the slot MRL is closed.
• Make sure the supported firmware version for the MP, the server, and the Lights-Out Advanced
KVM card is installed.
• Check that the Lights-Out Advanced and MP network cables are connected correctly.
• Check the LED link indicators on the bulkhead LAN port.
• Understand the Lights-Out Advanced RJ45 LAN connector LED definitions.
• Check that the cables are correctly connected to the Lights-Out Advanced bulkhead ports
(LAN, VGA, USB1, & USB2).
• Check for the use of the correct DNS name for access/connection.
• Check the web browser support and configuration/restrictions.
Table 16 lists possible problems with the Lights-Out Advanced KVM card, and provides suggested
solutions.
Table 16 General Troubleshooting
SolutionsProblem
Hardware problem:Graphics error:
Black screen. No text is displayed.
• Must have supported power enabled.
• Must have a functional mode-1 PCI-X slot. Try selecting
another mode-1 slot on same partition/backplane.
• Must have the card firmly seated in PCI-X/PCI-Xe
backplane slot.
• Must have a supported monitor.
• Must have verified cable connections to the card.
• Must have a functional Lights-Out Advanced KVM card.
Lights-Out Advanced KVM Card for sx2000 Servers 57
