• Set the link state to 10 BaseT.
MP:CM> LC -link t
• Set the remote console serial port address.
MP:CM> LC -web 2023
• Set the SSH console port address.
MP:CM> LC -ssh 22
Configuring DNS
To use the DNS command to display and modify the DNS configuration:
1. From the MP Main Menu, enter command mode.
2. At the MP:CM> prompt, enter DNS. The screen displays the current DNS data.
3. When prompted, enter A to select all parameters. The screen displays the current DHCP for
DNS servers status.
4. When prompted, enter Enabled or Disabled. The screen displays the current DHCP for
DNS domain name status.
5. When prompted, enter Enabled or Disabled. The screen displays the current register with
DDNS server value.
6. When prompted, enter Yes or No. The screen displays the current DNS domain name.
7. When prompted, enter a new value. The screen displays the primary DNS server IP address.
8. When prompted, enter a new value. The screen displays the optional secondary DNS server
IP address.
9. When prompted, enter a new value. The screen displays the optional tertiary DNS server IP
address.
10. When prompted, enter a new value.
The DNS configuration is updated as follows:
New DNS Configuration (* modified values):
* S - DHCP for DNS Servers : Disabled
* D - DHCP for DNS Domain Name : Disabled
R - Register with DDNS Server : Yes
* N - DNS Domain Name : mpdns.company.com
* 1 - Primary DNS Server IP : 192.0.2.1
2 - Secondary DNS Server IP :
3 - Tertiary DNS Server IP :
Enter parameter(s) to revise, Y to confirm, or [Q] to Quit: Y
-> DNS Configuration has been updated
[mpserver] MP:CM>
Configuring LDAP Extended Schema
The following procedure shows how to configure iLO 2 to use a directory server to authenticate a
user login using the iLO 2 MP TUI.
NOTE: The LDAP connection times out after 30 minutes of inactivity in Active Directory. For Novell
directory, there is no inactivity timeout.
To configure using the web interface, see “Group Accounts” (page 130).
NOTE: The LDAP feature is only available if you have the iLO 2 Advanced Pack license.
Configuring DNS 65
