To configure LDAP extended schema:
1. From the MP Main Menu, enter command mode.
2. At the MP:CM> prompt, enter LDAP.
3. To select Directory Settings, enter D. The current LDAP directory settings appear.
4. To select all parameters enter A. The current LDAP directory authentication status appears.
The local iLO 2 user accounts database status also appears. If enabled, the local iLO 2 user
database is used if there is an authentication failure using the LDAP Directory.
5. Enter D for disabled, or E for enabled. You must enter E if LDAP directory authentication is
disabled. The current LDAP server IP address appears.
6. Enter the IP address of the LDAP server. The current LDAP server port address appears.
7. Enter a new port number. The screen displays the current object distinguished name. This
specifies the full distinguished name of the iLO 2 device object in the directory service. For
example, CN=RILOE2OBJECT, CN=Users, DC=HP, DC=com. Distinguished names are
limited to 255 characters maximum plus one for the NULL terminator character.
8. Enter a new name. The Current User Search Context 1 appears.
9. Enter a new search setting. The Current User Search Context 2 appears.
NOTE: The context settings 1, 2, and 3 point to areas in the directory service where users
are located, so that users do not have to enter the complete tree structure when logging in.
For example, CN=Users, DC=HP, DC=com. Directory user contexts are limited to 127
characters maximum plus one for the NULL terminator character for each directory user context.
10. Enter a new search setting. The screen displays the Current User Search Context 3.
11. When prompted, enter a new search setting.
The updated LDAP configuration is as follows:
New Directory Configuration (* modified values):
* L - LDAP Directory Authentication : Enabled
M - Local MP User database : Enabled
* I - Directory Server IP Address : 192.0.2.1
P - Directory Server LDAP Port : 636
D - Distinguished Name (DN) : cn=mp,o=demo
1 - User Search Context 1 : o=mp
2 - User Search Context 2 : o=demo
3 - User Search Context 3 : o=test
Enter Parameter(s) to revise, Y to confirm, or [Q] to Quit: y
-> LDAP Configuration has been updated
Login Process Using Directory Services with Extended LDAP
You can choose to enable directory services to authenticate users and authorize user privileges
for groups of iLO 2s. The iLO 2 directory services feature uses the industry-standard LDAP. HP
layers LDAP on top of SSL to transmit the directory services information securely to the directory
servers. More information about using iLO with directory services is available from the HP website
at:
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00190541/c00190541.pdf?
jumpid=reg_R1002_USEN
HP provides a tool for Active Directory support of HP management processors. This tool,
HPQLOMIG.exe, is part of HP Directories Support for Management Processors softpaq
(SP31581.exe). It assists with installing the schema and snap-ins needed for Active Directory to
work with iLO 2 products including Integrity iLO 2. This is for set up and management. It will not
do automatic migration for you. For Integrity iLO 2, you must manually add iLO 2 objects to the
