Table 21 Commands and Associated Access Right (continued)
Access RightLocationCommand
MP Configuration AccessIT
MP Configuration AccessLC
MP Configuration AccessLDAP
Login AccessLS
Login AccessMA
MP Configuration AccessPARPERM
User Administration AccessPD
All for all supported partitionsPE
Login AccessPS
Server Power AccessPWRGRD
All for all supported partitionsRE
All for all supported partitionsRU (KMIX only)
MP Configuration AccessSA
SO 1. MP Wide Parameters - MP Configuration rights for all partitions to which
the user has access
2. User Parameters - User Admin rights for all partitions to which the user
has access
3. IPMI Password - MP Configuration rights for all partitions to which the
user has access
4. OS initiated FW - MP Configuration rights for all partitions to which the
user has access
5. Regenerate SSH Certificate - MP Configuration rights for all partitions
to which the user has access
MP Configuration AccessSYSREV
Login AccessTE
Login AccessWHO
XD 1. Parameters Checksum and Ping - Login rights for all partitions that user
has access to
2. Soft Reset for Master/Slave & IOX Master/Slave MP - MP Configuration
rights for all partitions to which the user has access
3. Clear Persistent Parameters - User Admin rights and MP Configuration
rights (for all partitions to which the user has access)
4. Reset Security Parameters - User Admin rights for all partitions to which
the user has access
5. Force/Recover Master - Slave FailOver - MP Configuration rights for all
partitions to which the user has access
6. Toggle Master/Slave FailOver Enable - MP Configuration rights for all
partitions to which the user has access
MP Configuration AccessDNS
MP Configuration AccessLOC
MP Configuration AccessSNMP
MP Configuration AccessUPS
MP Configuration AccessFW
72 Configuring DHCP, DNS, LDAP, and Schema-Free LDAP
