Table 21 Commands and Associated Access Right (continued)
Access RightLocationCommand
CI 1. View logs - Console rights for a partition
2. Clear logs - MP Configuration rights for all partitions to which the user
has access
Console AccessCO
Login AccessHE
SL 1. View SEL, FPL, LIVE - Login rights for all partitions to which the user has
access
2. View iLO 2 event log - Login rights for all partitions to which the user
has access
3. View MPEL Logs - MP Configuration rights for all partitions to which the
user has access
4. Clear SEL & FPL Logs - MP Configuration rights for all partitions to which
the user has access
Login AccessVFP
Login AccessX
MP Configuration AccessMPEL
Login AccessCommand MenuIO (sx2000 only)
All for all supported partitionsCommand MenuVM (sx2000 only)
These access rights work in conjunction with the three different kinds of partition user support
options.
Partition User Support Options
In a server that supports multiple partitions, the following options are available for partition users.
A user can be configured for any of the following partition usage levels:
Single Partition Use
A user could have access to any one partition with rights defined.
Multipartition User, Same Rights
A user can have access to multiple partitions of a server but with the same rights for all the partitions.
Multipartition User, Different Rights
A user can have access to multiple partitions with different rights for all the partitions.
If a server has multiple partitions, the following rules apply for a user:
• Each user, at the time of creation, is classified either as an all or #partition user. A
partition might or might not be configured in the system.
• Login rights are required for a user to login. These rights are checked before running each
command to ensure that LOGIN rights are not revoked in the interim. A user with L rights can
run all commands related to status and read-only commands.
• When a user tries to run partition-specific commands but the partition is not configured, a
message appears that the partition is not configured
• Special commands such as pe, ru, and re require a user to have all rights to all partitions.
These commands can affect cells that are considered ‘free cells’ (not associated with any
partitions). Therefore, this mandate applies to users before running special commands.
LDAP and MP Login for Integrity Cell-Based Servers 73
