Table 27 Events and Actions (continued)
FunctionsActionEvent
New events overwrite old MPEL events once the MPEL is full.MP Event Log - Stores
user action events
including user login
MPEL
The iLO 2 MPEL records the following events:
• iLO 2 MP login, logout attempts and login failure records
• MP firmware upgrade
• MP firmware activate event
• Console access
• Clearing of logs
MPEL logs cannot be cleared.
Formatting options are not available for MPEL.
The Live Logs feature enables you to apply a filter, and filter out logs by
cell or by partition, or to view only error logs.
Displays events, live as
they occur
Live Logs
The Clear Logs command clears both the FPL and SEL. It is useful for getting
a "clean log trace". A user with Console access right can view the System
Clears the activity and
error log buffers
Clear Logs
Event Log. Only a user with iLO Configuration access right can clear the logs.
Login rights are sufficient to view the logs. But for clearing the logs, iLO
Configuration rights are required for all the partitions to which user has access.
But MPEL logs cannot be cleared.
Keyword Format
For the event logs, the default format is Keyword (keyword plus hex). SEL and FPL provide formatting
options, the other two formats are raw hex mode and text mode. Text mode gives a multi-line
display that is more readable and decodes any physical location data.
The (D)ump command dumps the entire log in keyword format. It is useful for capturing the log
contents to a file and emailing it for analysis by support personnel.
Navigation
Navigation commands enable you to move forward or back a screen at a time, and to jump to a
specific log number or to the first or last log entry.
Table 28 lists the navigation commands and their actions.
Table 28 Navigation Commands
Action
Navigation
Command
Dump log starting at current block for capture and analysis (for SEL and FPL) Dump log starting
from the beginning (for MPEL)
D
Display first (oldest) blockF
Display last (newest) blockL
Jump to specified entry and display previous blockJ
Display next (forward in time) block+
Display previous (backward in time) block-
Repeat previous +/- command<cr>
Repeat previous +/- command<sp>
Display help?
Exit viewerCtrl-B
80 Using iLO 2
