NOTE: The MPEL log history display provides the same navigation commands as the FPL and
the SEL except for the D command.
MPEL log navigation provides the following filtering options:
Table 29 MPEL Log Navigation Filter
ActionMPEL Log Navigation Filter
Filter by User Login IDS : User Login
Filter by User Login Method (Serial, Telnet, SSH, WEB)P : Login Method
Filter by user IP Address (dotted decimal format)I : IP Address
Filter by date stamp of the record entries (MM/DD/YYYY)T : Date
Switch back to unfiltered stateU : Unfiltered
HE (Help): Display help for the menu or command in the MP Main Menu
HE displays help for the menu or command.
• If executed from the MP Main Menu, HE displays general information about iLO 2, and those
commands available in the MP Main Menu.
• If executed in command mode, HE displays a list of Command menu commands available. It
also displays detailed help information in response to a topic or command at the help prompt.
X (Exit): Exit iLO 2
X exits you from the MP Main Menu. If the terminal is the local serial port, the login prompt appears.
For all other types of terminals, you are disconnected from iLO 2.
Command Menu
The Command menu provides you with a set of standard command line interface commands that
help monitor and manage the server.
Table 30 lists the Command menu commands.
Table 30 Command Menu Commands
DescriptionCommand
Resets the BMC passwordsBP
Displays blade parameters
NOTE: This command is available only on a server blade.
BLADE
Configures asynchronous local serial portCA
Displays the current dateDATE
Resets all parameters to default configurationDC
Displays field replaceable unit (FRU) informationDF
Disconnects the LAN consoleDI
Sets the DNS configurationDNS
This command is only available to authorized HP service personnelFW
Displays help for the menu or commandHE
Displays or modifies system informationID
Text User Interface 81
