Table 30 Command Menu Commands (continued)
DescriptionCommand
Modifies the iLO 2 inactivity timeoutsIT
Displays the LAN configurationLC
Displays the LDAP configurationLDAP
License managementLM
Displays and configures locator LEDLOC
Displays the LAN statusLS
Remote power controlPC
Remote power mode controlPM
Configures the power restore policyPR
Displays the power management module statusPS
Resets the BMCRB
Resets the system through the RST signalRS
Sets access optionsSA
Configures SNMP parametersSNMP
Configures security optionsSO
Displays system processor statusSS
Displays all firmware revisionsSYSREV
Resets through transfer of control (TOC)TC
“Tell” (sends a message to other users)TE
Displays a user configurationUC
Displays connected iLO 2 usersWHO
Diagnoses or resets iLO 2XD
The following is a quick reference list that provides MP Command mode activities:
To access the Command menu, enter CM at the MP Main Menu.
To see all the available commands, enter HE LI at the MP:CM> prompt.
To access the Command menu help, enter HE at the MP:CM> prompt. The Command menu help
provides information on all the Command menu items.
To modify the inactivity timeout, enter the IT command. The inactivity timer aborts a command if
you do not complete it within a certain time period and redirects you back to the command prompt.
To abort most commands, enter Q at the point when the iLO 2 MP is asking for input.
To return to the MP Main Menu from any of these commands, press Ctrl-B.
Command Line Interface Scripting
A command line interface is provided for all commands to assist you in scripting. This section
provides syntax examples used in the iLO 2 MP command-line or scripted interface.
Typically, tools like Expect (see “Expect Script Example” (page 83)) and (http://expect.nist.gov/)
are used to string together several commands to accomplish a task. These scripting tools enable
82 Using iLO 2
