Replacement Instructions for the Air Bleeder Valve HP Modular Cooling System

c.
Remove the heat exchanger unit shipping brackets
from the MCS unit (3).
CAUTION: The heat exchanger unit weighs 23.6 kg
(52 lb) with the additional weight of the water. Use
extra caution when removing and replacing the top
heat exchanger unit because it might be higher than
your shoulders and is heavy and awkward to lift.
7. Pull the heat exchanger unit out toward you.
To replace this component, see "Replacing the heat
exchanger unit (on page 5)."
Removing the air bleeder valve
1. Reach into the access panel cut-out.
2. Using a pair of pliers, unscrew the air bleeder valve from
the check valve.
3. Remove the air bleeder valve from the MCS unit.
To replace this component, see "Replacing the air bleeder
valve (on page 5)."
