Appendix C Slot arrangement
The MSR1003-8 router provides slots for SICs. A DSIC can be installed if you remove the slot divider
between two SIC slots.
The slot number of fixed ports on the MSR1003-8 router is 0..
Table 6 Slot arrangement on the MSR1003-8 router
Router Slot arran
g
ement
MSR1003-8
: Slots for SICs
: Slot for the DSIC
