Field Description
Output queue : (Urgent queuing :
Size/Length/Discards) 0/100/0
Urgent queuing: Current number of packets in the queue,
maximum number of packets that can stay in the queue, and
number of dropped packets.
Link layer protocol packets, such as PPP negotiation packets
and keepalive packets, enter this queue.
Output queue : (Protocol queuing :
Size/Length/Discards) 0/500/0
Protocol queuing: Current number of packets in the queue,
maximum number of packets that can stay in the queue, and
number of dropped packets.
Packets with IP precedence 6 enter this queue.
Output queue : (FIFO queuing :
Size/Length/Discards) 0/75/0
FIFO queuing: Current number of packets in the first-in first-out
(FIFO) queue, maximum number of packets that can stay in the
queue, and number of dropped packets.
USB Modem State: Present
The presence state of the 3G modem (whether the 3G modem
is inserted in the device):
• Present.
• Not present.
RSSI Standby State: Normal
Main interface status in RSSI-based interface backup:
• Normal—The main interface is sending and receiving
packets correctly.
• Standby—The main interface has stopped sending and
receiving packets.
Transfer time: 00:01:30 Lasting time for the interface in the UP state.
Last clearing of counters: Never The last time when statistics on the interface was cleared.
Last 300 seconds input rate 0.00 bytes/sec,
0 bits/sec, 0.00 packets/sec
Average input rate in the last 300 seconds.
Last 300 seconds output rate 0.00 bytes/sec,
0 bits/sec, 0.00 packets/sec
Average output rate in the last 300 seconds.
Input: 280 packets, 205297 bytes
0 broadcasts, 0 multicasts
0 errors, 0 runts, 0 giants
0 CRC, 0 align errors, 0 overruns
0 dribbles, 0 aborts, 0 no buffers
0 frame errors
Received statistics on the cellular interface:
• broadcasts—Number of received broadcast packets.
• multicasts—Number of received multicast packets.
• errors—Number of error packets detected on the physical
layer.
• runts—Number of undersized packets received on the
serial interface.
• giants—Number of oversized packets received on the
serial interface.
• CRC—Number of normal-sized packets with CRC errors.
• align errors—Number of align error packets.
• overruns—Number of packets that the serial interface is
unable to process because the serial interface is overrun.
• aborts—Number of packets that are not received
successfully.
• no buffers—Number of packets that are discarded
because the buffer runs out.
• frame errors—Number of packets with frame errors.
