Field Description
Input: 280 packets, 205297 bytes
0 broadcasts, 0 multicasts
0 errors, 0 runts, 0 giants
0 CRC, 0 align errors, 0 overruns
0 dribbles, 0 aborts, 0 no buffers
0 frame errors
Received statistics on the cellular Ethernet interface:
• broadcasts—Number of received broadcast packets.
• multicasts—Number of received multicast packets.
• errors—Number of error packets detected on the physical
layer.
• runts—Number of undersized packets received on the
serial interface.
• giants—Number of oversized packets received on the
serial interface.
• CRC—Number of normal-sized packets with CRC errors.
• align errors—Number of align error packets.
• overruns—Number of packets that the serial interface is
unable to process because the serial interface is overrun.
• aborts—Number of packets that are not received
successfully.
• no buffers—Number of packets that are discarded
because the buffer runs out.
• frame errors—Number of packets with frame errors.
Output:189 packets, 210072 bytes
0 errors, 0 underruns, 0 collisions
0 deferred
Sent statistics on the cellular Ethernet interface:
• errors—Number of error packets detected at the physical
layer.
• underruns—Number of packets that fail to be forwarded
because the serial interface reads from memory at a slower
speed than it forwards packets.
• collisions—Number of packets with collisions detected.
• deferred—Number of deferred or timeout packets.
The brief information of interface(s) under
route mode:
Brief information about Layer 3 interfaces.
Link: ADM - administratively down; Stby -
standby
Link status:
• ADM—The interface has been administratively shut down.
To recover its physical state, use the undo shutdown
command.
• Stby—The interface is operating as a backup interface. To
see the primary interface, use the display standby state
command in High Availability Command Reference.
Protocol: (s) - spoofing
If the network layer protocol state of an interface is shown as
UP, but its link is an on-demand link or not present at all, its
protocol attribute includes the spoofing flag (an s in
parentheses).
Interface Abbreviated interface name.
Link
Physical link state of the interface:
• UP—The link is up.
• ADM—The link has been administratively shut down. To
recover its physical state, use the undo shutdown
command.
Protocol
Protocol connection state of the interface, which can be UP,
DOWN, or UP(s).
