R2511-HP MSR Router Series Interface Command Reference(V5)

2
Views
Ethernet interface view (combo interface)
Default command level
2: System level
Parameters
copper: Activates the copper(electrical) combo port.
fiber: Activates the fiber (optical) combo port.
Usage guidelines
The following matrix shows the command and router compatibility:
Command
MSR90
0
MSR93
X
MSR20-1
X
MSR20 MSR30 MSR50 MSR1000
combo
enable
No No No No
Applicable to only
MSR30-40 and
MSR30-60
Yes No
Combo interfaces are logical interfaces. A combo interface comprises one fiber combo port and one
copper combo port. The two ports cannot work simultaneously. If one port is enabled, the other port is
automatically disabled.
The LINK LED of a GE combo interface might be on when you insert or remove a transceiver module into
or from the combo interface whose fiber combo port is active on an MSR50 router, SIC-1GEC module,
XMIM-16FSW module, or XMIM-24FSW module. To solve the problem, shut down the combo interface
with the shutdown command and then bring it up with the undo shutdown command.
Examples
# Activate the copper combo port of combo interface GigabitEthernet 1/1.
<Sysname> system-view
[Sysname] interface gigabitethernet 1/1
[Sysname-GigabitEthernet1/1] combo enable copper
# Activate the fiber combo port of combo interface GigabitEthernet 1/1.
<Sysname> system-view
[Sysname] interface gigabitethernet 1/1
[Sysname-GigabitEthernet1/1] combo enable fiber
default
Use default to restore the default settings for an Ethernet interface or subinterface.
Syntax
default
Views
Ethernet interface view, Ethernet subinterface view
Default command level
2: System level
