Receiver alarm state is None.
Historical Statistics:
Last clearing of counters: Never
Data in current interval (150 seconds elapsed):
0 Loss Frame Alignment Secs, 0 Framing Error Secs,
0 CRC Error Secs, 0 Alarm Indication Secs, 0 Loss-of-signals Secs,
0 Code Violations Secs, 0 Slip Secs, 0 E-Bit error Secs.
Table 21 Command output
Field Description
E1 2/0 current state: UP State of the interface.
Description : E1 2/0 Interface Description of the interface.
Work mode Operating mode of the interface, which can be E1 or CE1.
Cable type Cable type of the interface.
Frame-format Frame format of the interface, which can be CRC4 or non-CRC4.
Source Clock
Operating mode of the source clock of the interface, which can be
master or slave.
Line Code Line code, which can be AMI or HDB3.
Idle Code Idle code, which can be 0x7E or 0xFF.
Itf type Interframe filling tag, which can be 0x7E or 0xFF.
Itf number Number of interframe filling tags between two successive frames.
Loopback Loopback state.
Alarm State Alarm state.
Historical Statistics Statistics on the interface.
Last clearing of counters The last time when statistics on the interface was cleared.
Data in current interval (150 seconds
elapsed):
0 Loss Frame Alignment Secs, 0
Framing Error Secs,
0 CRC Error Secs, 0 Alarm Indication
Secs, 0 Loss-of-signals Secs,
0 Code Violations Secs, 0 Slip Secs, 0
E-Bit error Secs
Error statistics in the current interval.
error-diffusion restraint config
Use error-diffusion restraint config to set the three parameters in error packets diffusion restraint.
Use undo error-diffusion restraint config to restore the default values of the three parameters.
Syntax
error-diffusion restraint config detect-timer renew-timer threshold
undo error-diffusion restraint config
