R2511-HP MSR Router Series Interface Command Reference(V5)

6
<Sysname> display interface ethernet 1/1 | include current state:|bytes
Ethernet1/1 current state: DOWN ( Administratively )
Line protocol current state: DOWN
Last 300 seconds input rate 0.00 bytes/sec, 0 bits/sec, 0.00 packets/sec
Last 300 seconds output rate 0.00 bytes/sec, 0 bits/sec, 0.00 packets/sec
Input: 0 packets, 0 bytes, 0 buffers
Output:0 packets, 0 bytes, 0 buffers
# Display brief information about all interfaces.
<Sysname> display interface brief description
The brief information of interface(s) under route mode:
Link: ADM - administratively down; Stby - standby
Protocol: (s) - spoofing
Interface Link Protocol Main IP Description
Aux0 UP UP --
Cellular0/0 DOWN DOWN --
GE0/0 UP UP 192.168.100.1 The interface for connecting RouterA.
Loop0 UP UP(s) -- --
MP0 DOWN DOWN --
NULL0 UP UP(s) -- --
Vlan1 DOWN DOWN 192.168.1.1
The brief information of interface(s) under bridge mode:
Link: ADM - administratively down; Stby - standby
Speed or Duplex: (a)/A - auto; H - half; F - full
Type: A - access; T - trunk; H - hybrid
Interface Link Speed Duplex Type PVID Description
GE0/1 DOWN auto A A 1
GE0/2 DOWN auto A A 1
GE0/3 DOWN auto A A 1
GE0/4 DOWN auto A A 1
Table 1 Command output
Field Description
Ethernet1/1 current state
State of the Ethernet interface:
• DOWN ( Administratively )—The Ethernet interface was shut down with
the shutdown command. The interface is administratively down.
• DOWN ( Link-Aggregation interface down )—The Ethernet interface is
physically down because the aggregate interface corresponding to the
aggregation group to which the Ethernet interface belongs was shut
down with the shutdown command.
• DOWN—The Ethernet interface is administratively up but physically
down (possibly because no physical link is present or the link has failed).
• UP—The Ethernet interface is both administratively and physically up.
Line protocol current state
Link layer state of the interface:
• DOWN—The interface is physically down.
• UP—The interface is physically up.
