R2511-HP MSR Router Series Interface Command Reference(V5)

145
Table 22 Command output
Field Descri
p
tion
T1 2/0 current state Physical state of the interface: up or down.
Description Description about the T1 interface.
Basic Configuration Basic configurations of the interface.
Work mode Operating mode of the T1 interface, T1 framed in this example.
Cable type
Cable type of the T1 interface, 100 ohm balanced in this
example.
Frame-format Frame format configured on the T1 interface: ESF or SF.
fdl FDL format: ANSI, ATT, or none.
Line code Line code: AMI or B8ZS.
Source clock
Source clock used by the interface: master for the internal clock or
slave for the line clock.
Data-coding Normal or inverted.
Idle code 0x7E or 0xFF.
Itf type Type of interframe filling tag: 0x7E or 0xFF.
Itf number Number of interframe filling tags.
Loop back
Loopback setting on the interface: local, payload, remote, or not
set.
Alarm State Alarm state.
Receiver alarm state Type of received alarm: none, LOS, LOF, RAI, or AIS.
Transmitter is sending remote alarm. Type of transmitted alarm: RAI, or none.
Pulse density violation detected The detected pulse density is incompliant with the specification.
SendLoopCode History:
inband-llb-up:0 times,
inband-llb-down:0 times.
fdl-ansi-llb-up:0 times, fdl-ansi-llb-down:0
times.
fdl-ansi-plb-up:0 times,
fdl-ansi-plb-down:0 times
History of loopback code sending to the peer end, including the
number of transmissions for each type of code, and the type of the
last sent code. (For more information, see the sendloopcode
command.)
BERT state:(stopped, not completed) BERT state: completed, stopped (not completed), or running.
Test pattern: 2^15, Status: Not Sync, Sync
Detected: 0
Test pattern in use (2^20 or 2^15), 2^15 in this example;
synchronization state, and the number of detected
synchronizations.
Time: 0 minute(s), Time past: 0 minute(s) Duration of the BERT test and time that has elapsed.
Bit Errors (since test started) Number of bit errors received since start of the BERT test.
Bits Received (since test started) Number of bits received since start of the BERT test.
Bit Errors (since latest sync) Number of bit errors received since last synchronization.
Bits Received (since latest sync) Number of bits received since last synchronization.
Historical Statistics: Historical statistics.
