R2511-HP MSR Router Series Interface Command Reference(V5)

7
Field Description
Internet protocol processing
Disabled indicates that IP packets cannot be processed.
For an interface configured with an IP address, this field changes to Internet
Address is.
Media type is Physical medium, twisted pair or optical fiber.
loopback not set
The loopback testing function is disabled.
For an interface configured with the loopback external or loopback internal
command, this field changes to loopback is set.
promiscuous mode not set The interface is operating in non-promiscuous mode.
Output queue (Urgent queue:
Size/Length/Discards)
Output queue (current message number in the urgent queue, maximum
number of messages allowed in the urgent queue, and number of discarded
messages).
Output queue (Protocol queue:
Size/Length/Discards)
Output queue (current message number in the protocol queue, maximum
number of messages allowed in the protocol queue, and number of
discarded messages).
Output queue (FIFO queuing:
Size/Length/Discards)
Output queue (current message number in the FIFO queue, maximum
number of messages allowed in the FIFO queue, and number of discarded
messages).
Last clearing of counters
Time when the reset counters interface command was last used to clear the
interface statistics. If the command was never used since the device was
started, this field displays Never.
Last 300 seconds input rate
Average input rate over the last 300 seconds in Bps, bps, and pps.
The statistics polling interval, 300 seconds in this example, can be
configured by using the flow-interval command.
Last 300 seconds output rate
Average output rate over the last 300 seconds in Bps, bps, and pps.
The statistics polling interval, 300 seconds in this example, can be
configured by using the flow-interval command.
Input Input packets.
Output Output packets.
# Display operating status information and related statistics of Layer 3 Ethernet subinterface Ethernet
1 / 1.1.
<Sysname> display interface ethernet 1/1.1
Ethernet1/1.1 current state: UP
Line protocol current state: UP
Description: Ethernet1/1.1 Interface
The Maximum Transmit Unit is 1500
Internet protocol processing : disabled
IP Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 0000-000f-0006
IPv6 Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 0000-000f-0006
Output queue : (Urgent queuing : Size/Length/Discards) 0/100/0
Output queue : (Protocol queuing : Size/Length/Discards) 0/500/0
Output queue : (FIFO queuing : Size/Length/Discards) 0/75/0
Last clearing of counters: Never
0 packets input, 0 bytes, 0 drops
