0 packets output, 0 bytes, 0 drops
Table 2 Command output
Field Description
Ethernet1/1.1 current state
State of the Ethernet subinterface:
• DOWN ( Administratively )—The Ethernet subinterface was shut
down with the shutdown command. The interface is
administratively down.
• DOWN ( Link-Aggregation interface down )—The Ethernet
subinterface is physically down because the aggregate interface
corresponding to the aggregation group to which the subinterface
belongs was shut down with the shutdown command.
• DOWN—The Ethernet subinterface is administratively up but
physically down (possibly because no physical link is present or the
link has failed).
• UP—The Ethernet subinterface is both administratively and
physically up.
Line protocol current state
Link layer state of the subinterface:
• DOWN—The interface is physically down.
• UP—The interface is physically up.
Internet protocol processing
Disabled indicates that IP packets cannot be processed.
For an interface configured with an IP address, this field changes to
Internet Address is.
IP Packet Frame Type Encapsulation format for IPv4 packets.
Hardware Address MAC address corresponding to the subinterface.
IPv6 Packet Frame Type Encapsulation format for IPv6 packets.
Output queue : (Urgent queue :
Size/Length/Discards)
Output queue : (Protocol queue :
Size/Length/Discards)
Output queue : (FIFO queuing :
Size/Length/Discards)
Packet statistics for the following output queues:
• Urgent queues.
• Protocol queues.
• FIFO queues.
Last clearing of counters
Time when the reset counters interface command was last used to clear
statistics on the subinterface.
If the command was never used since the device was started, this field
displays Never.
# Display detailed information about Layer 2 interface Ethernet 1/1.
<Sysname> display interface ethernet 1/1
Ethernet1/1 current state: UP
IP Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 0000-000f-0007
Description: Ethernet1/1 Interface
Loopback is not set
Media type is twisted pair, port hardware type is 100_BASE_TX
100Mbps-speed mode, full-duplex mode
Link speed type is autonegotiation, link duplex type is autonegotiation
Flow-control is not enabled
