R2511-HP MSR Router Series Interface Command Reference(V5)

169
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 900 Unavail Secs
Total Data (last 2 15 minute intervals):
0 Line Code Violations, 0 Path Code Violations
0 Ais Alarm Secs, 2087 Los Alarm Secs
52 Slip Secs, 2087 Fr Loss Secs, 0 Line Err Secs, 0 Degraded Mins
0 Errored Secs, 0 Bursty Err Secs, 0 Severely Err Secs, 2087 Unavail Secs
Table 24 Command output
Field Descri
p
tion
Serial2/0 Interface type and number.
Basic Configuration Basic configurations for the interface.
Input
Output
Statistics about the input and output.
Work mode T1 interface operating mode, T1 framed in this sample output.
Cable type
Cable type of the interface, 100 ohm balanced in this sample
output.
Frame-format Frame format configured on the interface: ESF or SF.
fdl FDL format: ANSI, ATT, or none.
Line code AMI or B8ZS.
Source Clock
Source clock used by the interface: master for the internal clock or
slave for the line clock.
Data-coding Normal or inverted.
Idle code Idle code, 0x7E or 0xFF.
Itf type Type of inter-frame filling tags: 0x7E or 0xFF.
Itf number Number of inter-frame filling tags.
Loop back
Loopback setting on the interface: local, payload, remote, or not
set.
Alarm State Alarm state.
Receiver alarm state Type of received alarm: none, LOS, LOF, RAI, or AIS.
Transmitter is sending remote alarm. Type of transmitted alarm: RAI, or none.
Pulse density violation detected The detected pulse density is incompliant with the specification.
SendLoopCode History:
inband-llb-up:0 times,
inband-llb-down:0 times.
fdl-ansi-llb-up:0 times, fdl-ansi-llb-down:0
times.
fdl-ansi-plb-up:0 times,
fdl-ansi-plb-down:0 times
History of loopback code sending to the far-end, including the
number of transmissions for each type of code, and the type of the
last sent code. (For more information, see "ft1 sendloopcode.")
BERT state:(stopped, not completed)
BERT state: completed, stopped (administratively stopped), or
running.
Test pattern: 2^15, Status: Not Sync, Sync
Detected: 0
Test pattern in use, 2^15 in this sample output; synchronization
state, and the number of detected synchronizations.
