9
The Maximum Frame Length is 1536
Broadcast MAX-ratio: 100%
Multicast MAX-ratio: 100%
PVID: 999
Mdi type: auto
Port link-type: access
Tagged VLAN ID : none
Untagged VLAN ID : 999
Port priority: 0
Last clearing of counters: Never
Last 300 seconds input: 0 packets/sec 74 bytes/sec 0%
Last 300 seconds output: 0 packets/sec 12 bytes/sec 0%
Input (total): 21322 packets, 1748554 bytes
- unicasts, - broadcasts, - multicasts, - pauses
Input (normal): 21322 packets, - bytes
1268 unicasts, 7560 broadcasts, 12494 multicasts, 0 pauses
Input: 0 input errors, 0 runts, 0 giants, - throttles
0 CRC, - frame, - overruns, - aborts
- ignored, - parity errors
Output (total): 1502 packets, 138924 bytes
- unicasts, 2 broadcasts, 406 multicasts, 0 pauses
Output (normal): - packets, - bytes
1094 unicasts, - broadcasts, - multicasts, - pauses
Output: 3 output errors, - underruns, - buffer failures
- aborts, 1 deferred, 2 collisions, 0 late collisions
- lost carrier, - no carrier
Table 3 Command output
Field Description
Ethernet1/1 current state
Physical state of the Ethernet interface. For more information, see Table
4.
IP Packet Frame Type Ethernet framing format on the interface.
Loopback Loopback testing status of the interface.
100Mbps-speed mode
The interface is operating at 100 Mbps.
This field displays Unknown-speed mode when the interface is
disconnected from the peer that it will automatically negotiate a port
speed with.
full-duplex mode
The interface is operating in full-duplex mode.
This field displays link duplex type is force link when the duplex mode
of the interface is fixed and not configurable.
Link speed type is autonegotiation The interface will negotiate a speed with its peer.
link duplex type is autonegotiation The interface will negotiate a duplex mode with its peer.
The Maximum Frame Length Maximum Ethernet frame length allowed on the interface.
Broadcast MAX-ratio
Broadcast suppression threshold as a percentage of the maximum
interface rate. When the threshold is exceeded, the interface drops
broadcast packets.
