Field Description
Unicast MAX-ratio
Unknown unicast suppression threshold as a percentage of the
maximum interface rate. When the threshold is exceeded, the
interface drops unknown unicast packets.
Multicast MAX-ratio
Multicast suppression threshold as a percentage of the maximum
interface rate. When the threshold is exceeded, the interface drops
multicast packets.
Allow jumbo frame to pass Jumbo frames are allowed to pass through the interface.
PVID Port VLAN ID.
Mdi type Cable type.
Port link-type Link type of the interface: access, trunk, or hybrid.
Tagged VLAN ID
VLANs for which the interface sends packets without removing VLAN
tags.
Untagged VLAN ID
VLANs for which the interface sends packets after removing VLAN
tags.
Last clearing of counters: Never
Time when the reset counters interface command was last used to clear
statistics on the interface. Never indicates that the reset counters
interface command was never used since the device was started.
Last 300 seconds input: 0
packets/sec 0 bytes/sec
Last 300 seconds output: 0
packets/sec 0 bytes/sec
Average rate of input and output traffic in the last 300 seconds, in pps
and Bps.
The statistics polling interval, 300 seconds in this example, can be
configured by using the flow-interval command.
Input (total): 21322 packets,
1748554 bytes
- unicasts, - broadcasts, -
multicasts, - pauses
Inbound traffic statistics (in packets and bytes) for the interface. All
inbound normal and abnormal packets (including unicast, broadcast,
and multicast), and pause frames were counted.
Input (normal): 21322 packets, -
bytes
1268 unicasts, 7560
broadcasts, 12494 multicasts, 0
pauses
Inbound normal traffic (including unicast, broadcast, and multicast)
and pause frame statistics (in packets and bytes) for the interface.
input errors Inbound packets with errors.
runts
Inbound frames that are shorter than 64 bytes, that are in correct
format, and that contain valid CRCs.
giants
Inbound frames larger than the maximum frame length supported on
the interface.
• For an Ethernet interface that does not permit jumbo frames, giants
refer to frames larger than 1536 bytes (without VLAN tags) or 1540
bytes (with VLAN tags).
• For an Ethernet interface that permits jumbo frames, giants refer to
frames larger than the maximum size of Ethernet frames that are
allowed to pass through, which is configured when you configure
jumbo frame support on the interface.
- throttles
Number of times that the port shut down because of buffer or CPU
overload.
