R2511-HP MSR Router Series Interface Command Reference(V5)

187
BERT state:(stopped)
Table 25 Command output
Field Descri
p
tion
E3 10/0 current state: UP E3 interface state.
Description : E3 10/0 Interface E3 interface description.
Current mode is CE3, loopback not set
Operating mode: CE3 or E3.
Loopback mode: payload, remote, local, or no
loopback.
Alarm: none Alarm information: los, ais, rai, or lof.
ERROR: 2 BPV, 0 EXZ, 0 FrmErr, 0 FEBE Statistics on each types of errors.
BERT state:(completed)
BERT state:
• Stopped—The test is stopped by the user
command.
• running.
• completed.
Test pattern: 2^7, Status: Not Sync, Sync Detected: 0
Test mode:
• 2^7.
• 2^11.
• 2^15.
• QRSS.
Synchronization state:
• Not Sync—Not synchronized due to a connection
failure.
• Sync—Synchronized.
Time: 2 minute(s), Time past: 2 minute(s) Total test time and past test time
Bit errors (since test started): 0 bits
Number of bit errors received since the test has
begun.
Bits received (since test started): 0 Mbits Total number of bits received since the test has begun.
Bit errors (since latest sync): 0 bits
Number of bit errors received since the last
synchronization.
Bits received (since latest sync): 0 Mbits
Total number of bits received since the last
synchronization.
E3 10/0 CE1 1 is up CE1 channel on the E3 interface.
Frame-format NO-CRC4, clock slave, loopback not set
Information about the E1 line:
• Framing format—None, 33, or 16.
• Clock source—Slave for the line clock and master
for the internal clock.
• Loopback—Local, remote, payload, or not set.
Receiver alarm state is none
Types of alarms: LOS, LOF, AIS, and RAI.
When the interface receives a LOS, LOF, or AIS and
sends a RAI to the peer, Transmitter is sending RAI is
displayed.
