R2511-HP MSR Router Series Interface Command Reference(V5)

219
Receiver alarm state is none
Line loop back deactivate code using inband signal last sent
BERT state:(stopped, not completed)
Test pattern: 2^11, Status: Not Sync, Sync Detected: 0
Time: 0 minute(s), Time past: 0 minute(s)
Bit errors (since test started): 0 bits
Bits received (since test started): 0 Kbits
Bit errors (since latest sync): 0 bits
Bits received (since latest sync): 0 Kbits
Table 27 Command output
Field Description
T3 2/0 CT1 1 is up State of T1 line 1 on the CT3 interface: up or down.
Frame-format ESF Framing format of T1: ESF or SF.
clock slave
Clock source used by the T1 line: slave for the line clock or master for
the internal clock.
loopback not set Loopback state or mode: local, remote, payload, or not set.
FDL Performance Report is disabled
Transmission of PPR in the FDL is disabled. You can enable that with
the t1 set fdl ansi command.
Transmitter is sending RAI
The transmitter of the T1 line is sending RAI signals. When the T1 line
receives LOS, LOF, or AIS signals, it sends RAI signals.
Receiver alarm state
Type of alarm signal that the T1 line can receive: LOS, LOF, AIS, or
RAI.
Line loop back activate code using
inband signal last sent
The loopback code sent last time is in-band LLB activation request
code.
BERT state BERT test state: running, complete, or stopped (not completed).
Test pattern
Status
Sync Detected
Test pattern in use, 2^11 in this example; synchronization state, and
the number of detected synchronizations.
Time
Time past
Duration of the BERT test and time that has elapsed.
Bit errors (since test started) Number of bit errors received since the start of the BERT test.
Bits received (since test started) Number of bits received since the start of the BERT test.
Bit errors (since latest sync) Number of bit errors received since the last synchronization.
Bits received (since latest sync) Number of bits received since the last synchronization.
t1 shutdown
Use t1 shutdown to shut down a T1 line on the CT3 interface.
Use undo t1 shutdown to bring up a T1 line.
Syntax
t1 line-number shutdown
