R2511-HP MSR Router Series Interface Command Reference(V5)

14
The brief information of interface(s) under bridge mode:
Link: ADM - administratively down
Speed or Duplex: (a)/A - auto; H - half; F - full
Type: A - access; T - trunk; H - hybrid
Interface Link Speed Duplex Type PVID Description
Eth0/3 UP 100M(a) F(a) A 1
Eth0/6 UP 100M(a) F(a) A 1
Eth0/8 UP 100M(a) F(a) A 1
Eth0/9 UP 100M(a) F(a) A 999
# Display the brief information about all but Ethernet interfaces.
<Sysname> display interface brief | exclude Eth
The brief information of interface(s) under route mode:
Link: ADM - administratively down
Protocol: (s) - spoofing
Interface Link Protocol Main IP Description
Aux0 DOWN DOWN --
Cellular0/0 DOWN DOWN --
Dia1 UP UP(s) --
Loop0 UP UP(s) 2.2.2.9
NULL0 UP UP(s) --
Vlan1 UP DOWN --
Vlan999 UP UP 192.168.1.42
# Display information about interfaces in the down state and the relevant causes.
<Sysname> display interface brief down
The brief information of interface(s) under bridge mode:
Link: ADM - administratively down; Stby - standby
Interface Link Cause
Eth6/4/0 DOWN Not connected
Eth6/4/1 DOWN OAM connection failure
Eth6/4/2 DOWN Not connected
Eth6/4/3 DOWN Not connected
Eth6/4/4 DOWN Not connected
Eth6/4/5 DOWN Not connected
Eth6/4/6 DOWN Not connected
Eth6/4/7 DOWN Not connected
Table 5 Command output
Field Description
The brief information of
interface(s) under route
mode:
The command displays brief information about Layer 3 interfaces.
Link: ADM -
administratively down;
Stby - standby
Link layer state of the interface:
• ADM—The interface has been shut down by the network administrator. To
recover its physical layer state, use the undo shutdown command.
• Stby—The interface is a standby interface. You can use the display standby
state command to check the corresponding primary interface.
