Field Description
The Maximum Transmit Unit is 1500,
Hold timer is 10(sec)
MTU of the BRI interface. The MTU defaults to 1500 bytes, and a
packet larger than the MTU is fragmented before it is sent. If
fragmentation is not allowed, the packet will be dropped.
Hold timer refers to the lifetime of a packet in a network. It is the
maximum amount of time that a packet can exist in the network
before being dropped. The hold timer of packets on the BRI
interface is set to 10 seconds.
Baudrate is 128000 bps, Timeslot(s)
Used: 1, 2
Bandwidth and timeslot of the BRI interface.
Internet Address is 6.6.5.5/24 Primary IP address of the BRI interface.
Encapsulation is ISDN Encapsulation protocol of the interface ISDN.
Output queue : (Urgent queuing : Length)
100
Urgent queuing specifies the maximum number of packets that can
stay in the queue.
Output queue : (Protocol queuing : Length)
500
Protocol queuing specifies the maximum number of packets that
can stay in the queue.
Packets with IP precedence 6 enter this queue.
Output queue : (FIFO queuing : Length)
75
FIFO queuing specifies the current number of packets in the first-in
first-out (FIFO) queue, maximum number of packets that can stay in
the queue.
Last clearing of counters: Never Last time when the interface statistics is cleared.
Last 300 seconds input rate 0.00
bytes/sec, 0 bits/sec, 0.00 packets/sec
Average input rate in the last 300 seconds.
Last 300 seconds output rate 0.00
bytes/sec, 0 bits/sec, 0.00 packets/sec
Average output rate in the last 300 seconds.
Input: 0 packets, 0 bytes
0 errors, 0 runts, 0 giants
0 CRC, 0 align errors, 0 overruns
0 aborts, 0 no buffers
0 frame errors
Received statistics on the BRI interface:
• broadcasts—Number of received broadcast packets.
• multicasts—Number of received multicast packets.
• errors—Number of error packets detected on the physical
layer.
• runts—Number of undersized packets received on the
interface.
• giants—Number of oversized packets received on the
interface.
• CRC—Number of normal-sized packets with CRC errors
received on the interface.
• align errors—Number of packets with alignment errors
received on the interface.
• overruns—Number of packets dropped because the input rate
of the interface exceeded the queuing capability.
• aborts—Number of packets that are not received successfully.
• no buffers—Number of packets that are discarded because
the buffer runs out.
• frame errors—Number of packets with frame errors.
